3.5T Full Rise Below Ground Heavy Duty Scissor Hoist
$6,300.00
The AL-3500BG Full Rise Below Ground Heavy Duty Scissor Hoist is engineered to sit flush with your concrete floor, offering seamless integration into your workshop. With a powerful lifting capacity of 3500kg (3.5 tonnes) and a maximum lift height of 2000mm (2m), this scissor lift provides an open platform design, ensuring easy access for all underbody repairs and maintenance tasks.
Product Code: AL-3500BG
$6,300.00
BROCHUREIntroducing the AL-3500BG Full Rise Below Ground Heavy Duty Scissor Hoist – the ultimate solution for underbody repairs and maintenance. With a robust 3500kg (3.5-tonne) lifting capacity and a maximum lift height of 2000mm (2m), this scissor hoist is built for demanding tasks. Its open platform design ensures easy access for all underbody work.
The AL-3500BG features air-operated safety locks with multiple locking positions and four hydraulic cylinders, delivering a smooth and synchronized lift every time. Available with single or three-phase power units, it offers convenient push-button operation and remote control for added ease of use.
Certified to Australian Standard WorkSafe Design, this scissor lift is perfect for busy automotive workshops and mine sites. Elevate your workshop’s efficiency and safety with the AL-3500BG Heavy Duty Scissor Hoist.
| Power unit option | Single Phase, Three Phase |
|---|
What's Included
- Scissor lift and power unit cart
- Single phase 15amp or Three phase power unit
- Installation Manual
What’s Not Included?
- Installation
- Hydraulic Oil
- Electrical and Air Connections (60-90PSI is required)
Workshop requirements
- 100mm flat level concrete surface is required
Warranty and Certification
- 5-year structural warranty*
- Australian WorkSafe Registered Design
Features
• WorkSafe Design Registered
• Flush mount space saving scissor hoist, completely free floor space when hoist is fully lowered
• Inground scissor lift requires a pit installation
• Powerful scissor structure with four hydraulic cylinders
• Ideal for wheel and brake work, tyre and wheel changing as well as new car preparation.
• Ergonomic power console
• Wide scissor span
Specifications
• Lifting capacity: 3000 kg
• Lifting height: 300 -1900 mm
• Width overall: 1950 mm
• Length overall: 1997 mm
• Power: 240V, 1Ph or 415V, 3Ph
• Gross weight: 868kg
• Packing Size: 1550*560*440 mm (1), 1160*450*560 mm (2)
